Tenda 8-Port10/100Mbps+2 Gigabit Desktop Switch With 8-Port PoE

75,64 €

Tasse incluse

Siamo Presenti sul MEPA. Il portale degli acquisti della Pubblica Amministrazione.

Descrizione

Tenda 8-Port10/100Mbps+2 Gigabit Desktop Switch With 8-Port PoE

Specifiche tecniche prodotto

Network standards	IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at
LED Indicator	10* Link/Ack LED indicators 1 * Power LED indicator
Interfaces	8 * 10/100 Base-TX Ethernet ports (Data/Power) 2 * 10/100/1000 Base-TX Ethernet ports (Data)
Transmission media	Recommended: CAT5/5e UTP or better
Dimension	177.5mmx104.0mmx26.0mm
Level of protection	Lightning protection for ports: 6KV Lightning protection for power: 4KV ESD: Air discharge: ±10kV Contact discharge: ±8kV
Forwarding mode	Store-and-forward
Switch capacity	5.6 Gbps
Packet forwarding rate	1.48Mpps
Buffer	448K
MAC address table	16K
PoE budget	Single port: AF: 15.4W, AT: 30W Whole device: 99W
Power consumption	/
Input voltage	100－240V AC 50/60Hz 51V /2.1A DC（Power Adapter ）
Mounting	Desktop mounting: support Wall mounting: support Rack mounting:non-support
Environment	Operating Temperature: 0℃~45℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
Certification	FCC、CE、RoHS
Funtions	Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation. VLAN Mode: 1-8 port can be isolated each other but 1-8 port can connect to 9/10 port after open VLAN to stop broadcast storm to increase forwarding rate of frame. Extend Mode: If Extend mode is enabled, the delivery distance of powering and network data is up to 250m (10Mbps).
